Explosion-protection relevant information
32 TTR200 OI/TTR200-EN
Pos: 23.1 /Überschri ften/1/D - F/Ex-techni sche Daten @ 0\mod_1132304 633775_3101.doc @ 3145
10 Explosion-protection relevant information
Pos: 23.2 /Überschriften/1.1/1-spaltig/S - U/TTX-E1 ... (Eigensicherheit) @ 0\mod_1141641215906_3101.d oc @ 3215
10.1 TTR200-E1… (intrinsically safe)
Pos: 23.3 /Ex-technische Daten/Temperatur/TTR200/TTR-E1... @ 17\mod_1202464337299 _3101.doc @ 156575
Approved for use in zone 0.
Designation:
• II 1G EEx ia IIC T6 (Zone 0)
• II 2 (1) G EEx [ia] ib IIC T6 (zone 1 [0])
• II 2 G (1D) Ex [iaD] ib IIC T6 (zone 1 [20])
Important
The Ex or ignition-proof designation is provided on the name
plate.
EC prototype test certificate: Refer to PTB 05 ATEX2017 X.
Temperature table
Permissible ambient temperature range Temperature
class
Device category 1
use
Device category 2 use
T6
-40 … 44 °C -40 … 56 °C
T5
-40 … 56 °C -40 … 71 °C
T4, T3, T2, T1
-40 … 60°C -40 … 85 °C
Pos: 23.4 /==== Wec hsel zwei- auf einspaltig === = @ 0\mod_1130421955859_3101. doc @ 3829
Change from one to two colu mns
Pos: 23.5 /Ex-technische Daten/Temperatur/TTR200/TTR-E1... (Stromdaten) @ 15\mod_1195650454703_3101.doc @ 142184
Safety specifications
Intrinsically safe EEx ia IIC explosion protection
Supply circuit Measurement current
circuit / passive
transducer (RTD)
Measurement current
circuit / active
transducer (RTD)
Max. voltage
U
i
= 30 V U
o
= 6,5 V U
o
= 1,2 V
Short-circuit current
I
i
= 130 mA I
o
= 25 mA I
o
= 50 mA
Max. power
P
i
= 0,8 W P
o
= 38 mW P
o
= 60 mW
Internal inductance
L
i
= 0,5 mH L
i
= 0 mH L
i
= 0 mH
Internal capacitance
C
i
= 5 nF C
i
= 49 nF C
i
= 49 nF
Maximum permissible
external inductance
L
o
= 5 mH L
o
= 5 mH
Maximum permissible
external capacitance
C
o
= 1,55 µF C
o
= 1,05 µF
Pos: 23.6 /==== Wec hsel ein- auf zweispaltig === = @ 0\mod_1130421847171_3101. doc @ 3828
Change from one to two colu mns
s: 23.7 /==== Wechsel z wei- auf einspaltig ==== @ 0\mod_1130421955859_3101. doc @ 3829
Change from one to two colu mns
Pos: 23.8 /Ex-technische Daten/Temperatur/TTR200/TTR-E2... @ 16\mod_1197556952453 _3101.doc @ 145675
Pos: 23.9 /==== Wec hsel ein- auf zweispaltig === = @ 0\mod_1130421847171_3101. doc @ 3828
Change from one to two colu mns
Pos: 24 /Überschrif ten/1/V - Z/Zulassungen @ 0\ mod_1138627017510_31 01.doc @ 3172
Approvals
10.2 TTR200-E2… (non-incendive)
Approved for use in zone 2.
Designation:
• II 3 G EEx n A II T6
Important
The Ex or ignition-proof designation is provided on the name
plate.
ABB manufacturer's declaration in accordance with ATEX directive
Temperature table
Temp.- class Device category 2 use
T6 -40 … 56 °C
T5 -40 … 71 °C
T4 -40 … 85 °C
11 Approvals
Pos: 25 /Technische Da ten / Datenblatt/Tempera tur/TTR/Zertifi zierungen @ 15\mod_11948 76510140_3101.doc @ 139987
CE mark:
The TTR200 meets all requirements for the CE mark in accordance
with IEC 61326 (2006).
Ignition protection:
The TTR200 complies with the requirements of ATEX directive 94/9
EC. For additional information, refer to the section "Explosion-
protection relevant information").
