Specifications
44 TZIDC, TZIDC-110, TZIDC-120 42/18-84-EN
9.2.6 Transmission data and influences
Output Y1
Increasing: Increasing output signal 0 ... 100 %
Increasing pressure at output Y1
Decreasing: Increasing output signal 0 ... 100 %
Decreasing pressure at output Y1
Characteristic deviation < 0,5 %
Tolerance band 0.3 ... 10 %, adjustable
Dead band 0,1 ... 10 %, adjustable
Resolution (A/D conversion) > 16000 steps
Sample rate 20 ms
Influence of ambient temperature <
0.5 % per 10 K
Influence of vibration <
± 1 % to 10 g and 80 Hz
Seismic requirements
Meets requirements of DIN / IEC 68-3-3 Class III for strong and
strongest earthquakes.
Influence of mounting orientation
Not measurable.
Meets the requirements of the following directives
- EMC Directive 2004/108/EC
- EC Directive for CE conformity marking
9.2.7 Environmental capabilities
Ambient temperature
For operation, storage and transport: -40 … 85 °C (-40 ... 185 °F)
When using proximity switches
SJ2-S1N (NO):
-25 … 85 °C (-13 ... 185 °F)
Relative humidity
Operational (with closed housing
and air supply switched on):
95 % (annual average),
condensation permissible
Transport and storage: 75 % (annual average), non-
condensing
9.2.8 Housing
Material / Degree of protection
Aluminum, protection class IP 65 (optional IP 66) / NEMA 4X
Surface / Color
Electrostatic dipping varnish with epoxy resin, stove-hardened.
Case varnished black, RAL 9005, matte, housing cover Pantone
420.
Electrical connections
Screw terminals:
Max. 1.0 mm
2
(AWG 17) for options
Max. 2.5 mm
2
(14 AWG) for bus connector
IMPORTANT (NOTE)
Do not expose the terminals to strain.
Four thread combinations for cable entry and pneumatic
connection
- Cable: thread 1/2-14NPT, air pipe: thread 1/4-18 NPT
- Cable: thread M20 x 1,5, air pipe: thread 1/4-18 NPT
- Cable: thread M20 x 1,5, air pipe: thread G 1/4
- Cable: thread G 1/2, air pipe: thread Rc 1/4
(Optional: With cable gland(s) and pipe plugs if necessary)
Weight
1,7 kg (3,75 lb)
Mounting orientation
Any
9.2.9 Options
Module for the emergency shutdown function
Supply voltage 24 V DC (20 ... 30 V DC) (galvanically
isolated from input signal)
Safe position is activated
when Explosion protection
voltage < 5 V see certificate
(operating instructions)
A separate 24 V DC signal is normally applied to the emergency
shutdown module, which connects through the signal from the
microprocessor to the I/P module.
When the 24 V DC signal is interrupted, the pneumatic module
executes the respective safety function, depending on the mechanical
construction.
The positioner output Y1 is depressurized, and the valve is moved to
the safe position. In case of a double-acting actuator the second
output Y2 is additionally pressurized.
IMPORTANT (NOTE)
The emergency shutdown module can only be used with
pneumatics with the safe position “fail-safe”.
The emergency shutdown module works independently of the mother
board, i.e. all information from the final control element is available in
the supervisory process control system at any time.
Digital position feedback with proximity switches
1)
Two proximity switches for independent position signaling. Switching
points adjustable between 0 … 100 %
Current circuits acc. to DIN 19234 / NAMUR
Supply voltage 5 ... 11 V DC
Signal current < 1 mA Switching state logical “0“
Signal current > 2 mA Switching state logical “1“
