7.1.2 Sample parameters
"Change the zero position of the LCD screen from clockwise (CLOCKW) to counter-
clockwise stop (CTCLOCKW)"
Starting position: The positioner operates in mode 1.1 in the operating level.
1. Switch to the configuration level:
• Press and hold
and simultaneously
• Press
briefly
• Wait until the countdown goes from 3 to 0
• Release
and
is displayed
2. Switch to parameter group 3._:
• Press and hold
and simultaneously
• Press
twice briefly
is displayed
• Release
and
is displayed
3. Select parameter 3.2:
• Press
and hold
• Press
twice briefly
is displayed
• Release
4. Change parameter settings:
• Press
briefly to select
