Specifications
46 TZIDC, TZIDC-110, TZIDC-120 42/18-84-EN
9.3.2 Device name
Device name ABB TZID-C120-TAG
Dev. ID 0003200028-TZID-C120XXXXXXXXXX
9.3.3 Output
Range 0 …6 bar (0 … 90 psi)
Air capacity
at 1.4 bar (20 psi)
supply pressure
5.0 kg/h = 3.9 Nm
3
/h=2.3 scfm
at 6 bar (90 psi)
supply pressure
13 kg/h = 10 Nm
3
/h = 6.0 scfm
Output function For single or double-acting actuators,
air is vented from actuator or actuator
is blocked in case of (electrical) power
failure
Shut-off values
End Position 0 % = 0 ... 45 %
End position 100 % = 55 … 100 %
9.3.4 Travel
Ste
Rotation angle
Used range
25 … 120° rotary actuators, optionally 270°
25 … 60° linear actuators
Travel time
prolongation
Setting range 0 ... 200 seconds, separately for each
direction
9.3.5 Air supply
Instrument air free of oil, water and dust to DIN/ISO
8573-1. Pollution and oil content
according to Class 3 (purity: max.
particle size = 5 µm, max. particle density
= 5 mg / m
3
; oil content: max.
concentration = 1 mg / m
3
; pressure dew
point: 10 K below operating temperature)
Supply pressure 1.4 ... 6 bar (20 ... 90 psi)
IMPORTANT (NOTE)
Do not exceed the maximum operating pressure of the
actuator!
Air consumption < 0.03 kg/h / 0.015 scfm (independent
of supply pressure)
9.3.6 Transmission data and influences
Direction of action (output signal or pressure in actuator)
Increasing Increasing output signal 0 ... 100 %
Increasing pressure y1 in the actuator
Decreasing Increasing output signal 0 ... 100 %
Decreasing pressure y1 in the actuator
Characteristic deviation < 0.5 %
Tolerance band 0.3 ... 10 %, adjustable
Dead band 0.1 ... 5 %, adjustable
Resolution (A/D conversion) > 16000 steps
Sample rate 20 ms
Influence of ambient
temperature
< 0.5 % for each 10 K
Influence of vibration <
± 1 % to 10 g and 80 Hz
Seismic requirements
Meets requirements of DIN / IEC 68-3-3 Class III for strong and
strongest earthquakes.
Influence of mounting orientation
Not measurable.
Meets the requirements of the following directives
- EMC Directive 2004/108/EC as of December 2004
- EC Directive for CE conformity marking
9.3.7 Environmental capabilities
Ambient temperature
For operation, storage and transport: -40 … 85 °C (-40 ... 185 °F)
When using proximity switches
SJ2-S1N (NO):
-25 … 85 °C (-13 ... 185 °F)
Relative humidity
Operational (with closed housing
and air supply switched on):
95 % (annual average),
condensation permissible
Transport and storage: 75 % (annual average), non-
condensing
