Parameter descriptions
82 TZIDC, TZIDC-110, TZIDC-120 42/18-84-EN
11.2.2 Parameter description
w
Parameter Display Function Parameter Unit Factory setting Customer
setting
P1._ STANDARD
P1.0 ACTUATOR
Actuator type
LINEAR, ROTARY --- LINEAR
P1.1 AUTO_ADJ
Auto adjust
Function --- --- ---
P1.2 TOL_BAND
Tolerance band
0,30 … 10,00 % 0,30
P1.3 DEADBAND
Dead band
0,10 … 10,00 % 0,10
P1.4 TEST
Test
Function --- --- ---
P1.5
1)
ADRESS
Busadresse
1 … 126 --- 126 ---
P1.6 EXIT
Return to operat. level
Function --- --- ---
P2._ SETPOINT
P2.0 --- --- ---
P2.1 --- --- ---
P2.2 CHARACT
Characteristic curve
LINEAR, EP 1:25, 1:50, 25:1, 50:
1,USERDEF
--- LINEAR
P2.3 ACTION
Action of the output
DIRECT, REVERSE --- DIRECT
P2.4 SHUT-CLS
Shut-off range 0%
OFF, 0,1 … 45 % off
P2.5 RAMP^
Set point ramp, up
OFF, 0,1 … 999,9 sec off
P2.6 RAMPˇ
Set point ramp, down
OFF, 0,1 … 999,9 sec off
P2.7 SHUT-OPN
Shut-off range 100%
OFF, 80.0 … 100 % off
P2.8 EXIT
Return to operat. level
Function --- --- ---
P3._ ACTUATOR
P3.0 MIN_RGE
Min. of operating range
0,0 … 100,0 % 0,0
P3.1 MAX_RGE
Max. of operating range
0,0 … 100,0 % 100,0
P3.2 ZERO_POS
Zero position
CLOCKWISE, CTCLOCKWISE --- CTCLOCKWISE
P3.3 EXIT
Return to operat. level
Function --- --- ---
P4._, P.5_ --- --- ---
P6._ MAN_ADJ
P6.0 MIN_VR
Min. operating range
0,0 … 100,0 % 0,0
P6.1 MAX_VR
Max. operating range
0,0 … 100,0 % 100,0
P6.2 ACTUATOR
Actuator type
LINEAR, ROTARY --- LINEAR
P6.3 SPRNG_Y2
Spring action (Y2)
CLOCKWISE, CTCLOCKWISE --- CTCLOCKWISE
P6.4 ADJ_MODE
Auto adjust mode
FULL, STROKE, CTRL_PAR, ZE
RO_POS, LOCKED
--- FULL
P6.5 EXIT
Return to operat. level
Function --- --- ---
P7._ CTRL_PAR
P7.0 KP^
KP value, up
1,0 … 100,0 --- 1,0
P7.1 KPv
KP value, down
1,0 … 100,0 --- 1,0
P7.2 TV ^
TV value, up
0 … 1000 msec 100
P7.3 TVv
TV value, down
0 … 1000 msec 100
P7.4 GOPULSE^
Go pulse, up
0 … 200 msec 0
P7.5 GOPULSEv
Go pulse, down
0 … 200 msec 0
P7.6 Y-OPFSET^
Y offset, up
Y-Min … 100,0 % 40,0
P7.7 Y-OFFSETv
Y offset, down
Y-Min … 100,0 % 40,0
P7.8 --- --- ---
P7.9 TOL_BAND
Tolerance band
0,30 … 10,00 % 0,8
P7.10 TEST
Test
Function --- --- ---
P7.11 EXIT
Return to operat. level
Function --- --- ---
P8._, P9._,
P.10_
--- --- ---
P11._ FS/IP
P11.0 FAIL_POS
Save position selection
ACTIVE, INACTIV --- INACTIV
P11.1 FACT_SET
Factory setting
Function --- --- ---
P11.2 IP_TYP
I/P module type
NO_F_POS,F_SAFE_1, F_SAF
E_2, F_FREEZE1, F_FREEZE2
--- NO_F_POS
P11.3 EXIT
Return to operat. level
Function --- --- ---
1) only TZIDC-110
