Specifications
42/18-84-EN TZIDC, TZIDC-110, TZIDC-120 45
Direction of action (logical state)
Position
Proximity switch < Lim. 1 > Lim. 1 < Lim. 2 > Lim. 2
SJ2-SN (NC) 0 1 1 0
SJ2-S1N (NO) 1 0 0 1
IMPORTANT (NOTE)
When using SJ2_S1N (NO), the TZIDC positioner may only
be used at an ambient temperature range from -25 ... 85 °C
(-13 ... 185 °F).
Digital position feedback with 24 V microswitches
1)
Two microswitches for independent position signaling. Switching
points adjustable between 0 … 100 %.
Voltage max. 24 V AC / DC
Load rating max. 2 A
Contact surface 10 µm Gold (AU)
Mechanical position indicator
Indicator disk in enclosure cover, linked with positioner feedback shaft.
IMPORTANT (NOTE)
These options are also available for retrofitting by Service.
1)
The proximity switches or 24 V microswitches for digital feedback
are activated directly via the positioner axis and can only be
used in combination with the optionally available mechanical
position indicator.
9.2.10 Accessories
Mounting material
- Attachment kit for linear actuators to DIN/IEC 534 / NAMUR
- Attachment kit for rotary actuators to VDI / VDE 3845
- Attachment kit for integral mounting to control valves
- Attachment kit for actuator-specific attachment upon request
Pressure gauge block
- With pressure gauges for supply and output pressure.
- Pressure gauges with housing ø 28 mm (1.1 inch), with
connection block in aluminum, black
- Installation material for mounting on positioner
Filter regulator
All metal version in brass, varnished black, bronze filter element
(40 µm) and condensate drain.
Max. pre-pressure 16 bar (232.06 psi), output adjustable to
1.4 ... 6 bar (20 ... 90 psi)
PC software for configuration and operation
DSV401 (SMART VISION) with DTM available on CD-ROM
9.3 TZIDC-120
9.3.1 Communication
Specification
FOUNDATION Fieldbus, version 1.5
Physical Layer
Model 113, 121 (IEC 61158-2)
Transmission rate
31.25 Kbit/s
Block types
1 AO Function block
1 PID block
1 Resource block
1 Transducer block
1 physical block
Block class
AO block: standard
PID block: enhanced
Resource block: enhanced
Transducer block: custom
Number of linkage objects
22
Device description (DD)
Rev. No. 1 (file name 0201.ffo,
0201.sym)
File
Common file format (file name:
020101.cff)
Max. execution time
AO block: 40 milliseconds
PID block: 50 milliseconds
Supply voltage
Power feed from the fieldbus
9.0 … c 32.0 V DC
Max. permissible voltage
35 V DC
Power consumption
11.5 mA
Current in the event of an
error
15 mA (11.5 mA + 3.5 mA)
FF Certification
Registered with ITK 4.51, Dec.2003
IT Camp. Number IT023200
Device name
ABB TZIDC, TZIDC-110, TZIDC-
120-TAG
Dev. ID
0003200028-TZIDC, TZIDC-110,
TZIDC-120XXXXXXXXXX
Device address
Between 10 and 247, default
address 23
ATEX certificate for FISCO
Yes
Insensitive to reversed
polarity
Yes
Class
LM profile 32L, 31 PS
Factory default
The positioner is not delivered in an
aligned state. To adjust the
operating range and control
parameters, an automatic
configuration must be run on the
unit. Otherwise, the transducer block
remains in out-of-service mode.
Diagnostic functions
Self-diagnostics for the positioner
hardware and software, valve
diagnostics with enhanced alarm
handling
