Ex relevant specifications
42/18-84-EN TZIDC, TZIDC-110, TZIDC-120 49
Electrical data
In intrinsically safe explosion protection types
Ex ib IIC / Ex ia IIC or Ex iaD, only for connection to a certified
intrinsically safe circuit
Signal circuit
(Terminal +11 / -12)
Maximum values:
U
i
= 30 V
I
i
= 320 mA
P
i
= 1.1 W
C
i
= 6.6 nF
L
i
negligibly small
Contact input
(Terminal +81 / -82)
Maximum values:
U
i
= 30 V
I
i
= 320 mA
P
i
= 1.1 W
C
i
= 4.2 nF
L
i
negligibly small
Switch output
(Terminal +83 / -84)
Maximum values:
U
i
= 30 V
I
i
= 320 mA
P
i
= 500 mW
C
i
= 4.2 nF
L
i
negligibly small
Mechanical digital feedback
(Terminals Limit1 +51 / -52
or Limit2 +41 / -42)
For max. values, see EC-type-examination test certificate
number PTB 00 ATEX 2049 X
Proximity switches manuf. by Pepperl & Fuchs
Plug-in module for digital
position feedback
(Terminal +51 / -52) or
+41 / -42)
Maximum values:
U
i
= 30 V
I
i
= 320 mA
P
i
= 500 mW
C
i
= 3.7 nF
L
i
negligibly small
Plug-in module for analog
position feedback
(Terminal +31 / -32)
Maximum values:
U
i
= 30 V
I
i
= 320 mA
P
i
= 1.1 W
C
i
= 6.6 nF
L
i
negligibly small
Plug-in module for shutdown
contact input
(Terminal +51 / -52) or
+85 / -86)
U
i
= 30 V
I
i
= 320 mA
P
i
= 1.1 W
C
i
= 3.7 nF
L
i
negligibly small
Local communication
interface (LKS)
Only for connection to a programmer outside the potentially
explosive area.
IMPORTANT (NOTE)
• The local communication interface (LKS) may only be operated at Um ≤ 30 V DC outside
the potentially explosive area.
• The equipment may only be used as a II 2 D type device in areas where the level of
mechanical danger is "low".
