Channel
Specifies the channel mapped to each trace. It is possible to map any channel to any
trace, and one channel can be mapped to any number of traces. If the reference channel
is enabled, it will be mapped to the trace as specified by the corresponding channel.
• Changing channel mapping
― Press <ARROWS> to select the wanted trace in the channel column
― Press <NUMBERS> to change the input channel of the trace
• Map all channels in forward direction (channel 1 to trace 1, 2 to 2 etc)
― Press <ARROWS> to select any trace in the channel column
― Press <SHIFT> + <+>
• Map all channels in reverse direction (channel 24 to trace 1, 23 to 2 etc for a 24
channel instrument)
― Press <ARROWS> to select any trace in the channel column
― Press <SHIFT> + <->
Polarity
Specifies the polarity of the recorded signal. If the polarity is positive, the signal will
be stored as is. If the polarity is negative, the signal will be inverted before it is stored.
• Changing polarity on one trace
― Press <ARROWS> to select the wanted trace in the polarity column
― Press <SPACE> to toggle the polarity
Or
― Press <+> to set a positive polarity
Or
― Press <-> to set a negative polarity
• Changing polarity on all traces
― Press <ARROWS> to select any trace in the polarity column
― Press <SHIFT> + <SPACE> to toggle the polarity on all traces
Or
― Press <SHIFT> + <+> to set all traces to a positive polarity
Or
― Press <SHIFT> + <-> to set all traces to a negative polarity
