ABEM Terraloc Pro 2
62
• Changing a value
― Press <ARROWS> to select the X, Y or Z value to be changed
― Press <NUMBERS> and possibly <-> and <.> to construct a valid value
― Press <ENT> to set the value and move down to the next value
When the first and second value has been given then the following values can be entered
quicker given that the distances are the same.
• Quick completion
― Press <CTRL> + <DOWN>
This will add the difference between the value in the first row and the second
row to the value in the second row and enter this value in the third row.
This can then be repeated for the following rows.
Keep holding <CTRL> + <DOWN> and all values for the current column will
be filled in.
If the value on the second row is larger than the one in the first row the
difference will be added to the value in the second row and entered in the third
row etc, for example starting with 0 on the first row and 5 on the second row
will produce 10, 15, 20 etc in the following rows.
If the value on the second row is smaller than the one in the first row the
difference will be subtracted from the value in the second row and entered in
the third row etc, for example starting with 100 on the first row and 95 on the
second row will produce 90, 85, 80 etc in the following rows.
Note! Both positive and negative values are allowed
• Opening the Layout Helper dialog (see chapter 4.6.10) when the marker is located
in the receiver locations part of the dialog
― Press <SPACE>
Move-ups
Describes how the source, receivers and the receiver connected to the reference channel
(if any) are updated when a record has been finished.
• Changing a value
― Press <TAB> to select the dX, dY or dZ value to be changed
― Press <NUMBERS> and possibly <-> and <.> to construct a valid value
― Press <TAB> to set the value and move to the next value
Roll-along
