Installation – Load management with homeCLU |

Load management with homeCLU

Using the separately available homeCLU / PZ42D-00A03 dynamic control unit, load management can be set up for

up to six wallboxes of type eMH1. The following prerequisites apply:

Wiring up and configuration of the homeCLU charging system is described in the separate homeCLU Installation

Manual.

Installation on mounting pole or mounting plate

The following installation options are available for the Wallbox eMH1 (see “Accessories” on page 7):

 Mounting pole STEMHX0 / PZ42D-00B01

STEMHX0 / PZ42D-00B01 is designed for the outdoor installation of the Wallbox eMH1. Its sturdy aluminium housing

offers stability in open areas. The adapter plate ADPEMH1 and the prefabricated concrete foundation BFMSTX1 are

also required for installation. Further information is contained in the separate manual for the STEMHX0 / PZ42D-

00B01.

 Mounting plates WHEMH10 / PZ42D-00A04 and 1W0001 / PZ42D-00A06

If required, the Wallbox eMH1 can be installed at the installation site on a mounting plate.

y The WHEMH10 / PZ42D-00A04 has a cable storage holder for the charging cable of the Wallbox eMH1.

y In addition to the cable storage holder, the 1W0001 / PZ42D-00A06 also provides a key switch, which can be

used to bar or allow charging procedures in a targeted manner:

You can find the homeCLU Installation Manual, the manuals for the charging pole STEMHX0 / PZ42D-00B01, as

well as for the mounting plates WHEMH10 / PZ42D-00A04 and 1W0001 / PZ42D-00A06 at:

https://www.toyota-tech.eu https://www.lexus-tech.eu
