Introduction to the Wallbox eMH1 – Accessories |
7
Accessories
The following accessories for the Wallbox eMH1 are available separately:
STEMHX0 / PZ42D-00B01
Anodised aluminium mounting pole for fixing wallboxes using suitable adapter
plates
h = 1,495 mm, b = 150 mm, t = 150 mm
ADPEMH1 / PZ42D-00A05
Mounting plate for fixing the Wallbox eMH1 to the pole
h = 261 mm, b = 220 mm, t = 3 mm
WHEMH10 / PZ42D-00A04
Mounting plate with cable storage holder for all Wallboxes eMH1
h = 482 mm, b = 226 mm, t = 93 mm
1W0001 / PZ42D-00A06
Mounting plage with key switch and cable storage holder for all Wallboxes
eMH1 with EVCC2
h = 482 mm, b = 226 mm, t = 101 mm
homeCLU / PZ42D-00A03
Dynamic control unit to optimise the charging of electric vehicles in domestic
settings
h = 135 mm, b = 145 mm, t = 70 mm
Further information and documents regarding your wallbox and accessories are available at:
https://www.toyota-tech.eu https://www.lexus-tech.eu
