Introduction to the Wallbox eMH2 – Accessories |
11
E017869
For all eMH2 model variants, except bundle products: Set of ID tag cards (5 pcs)
to extend user pool
POLEMH2
Galvanised sheetmetal mounting pole for direct installation of a Wallbox eMH2
h = 1,647mm, w = 285mm, d = 180mm
EMH9999
Precast concrete foundation for outdoor ground installation of the POLEMH2
h = 650mm, w = 430mm, d = 190mm
WPR12
Weather shield for installation on an exterior wall or the mounting pole
POLEMH2
h = 142mm, w = 395mm, d = 225mm
CABHOLD
Cable holder with charging plug receptacle for installation on an exterior wall or
the mounting pole POLEMH3
h = 187mm, w = 76mm, d = 105mm
E3BLTE1
Accessory package with LTE USB stick and LTE antenna for installation in ABL
Controller wallboxes
LTE
E3BWLAN
USB WiFi dongle for installation in ABL Controller wallboxes
TE001
Multipurpose measuring device for security checks according to IEC/EN61557,
as well as for testing charging stations via the adapter TE002, suitable for TN,
TT, and IT protective earthing systems
TE002
EVSE and vehicle simulation adapter according to IEC 61851 for checking the
function and electrical safety of charging stations
N PE
L1 L2 L3
LAK32A3
Type 2 charging cable according to IEC 62196-2, up to 32A 240/415VAC,
3-phase, length ca.4m
