| Installation – Affixing the label in accordance with DIN EN 17186-2019

9 Replace the electronic components cover onto the

housing base and fix it into place with the screw

you removed in Step 3.

10 Switch the electricity supply of the wallbox back on.

NOTE

Setting up communication via LTE USB stick

Setting up the LTE USB stick for use with your wallbox is described from section "Setting up data communica-

tion" on page34 onwards.

11 Hook the housing cover onto the upper edge of the

housing base and lock it using the housing cover

key.

Affixing the label in accordance with DIN EN 17186-2019

In accordance with DIN EN 17186-2019, a graphical indication of the compatibility of vehicles and the charging infra-

structure is mandatory for commercial use. Your charging station therefore comes with a sticker which the operator

must position near the charge point after the installation has been completed.

Wallbox eMH2 with charging socket

 One sticker with black writing on a white background

is supplied for this variant.

 ABL recommends affixing the sticker in the position

shown on the right-hand side.
