ABL Wallbox eMH2 Installation Manual

| Appendix – Technical specifications
52
Appendix
Technical specifications
Controller series
Model code 2W2240* 2W2241
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 22kW
Charging connection Type 2 charging socket, 1 pc Type 2 charging cable, 1 pc
Phase system 3-phase
Terminal blocks Direct connection to RCD, PE to rail mount terminal block, max. 5 × 16mm²
Residual Current Devices Type A RCD, 30mA
DC fault current detection DC-RCM, I
Δn d.c.
≥ 6mA
Overcurrent protection
Integrated into firmware, disconnection at
110% after 100seconds, at 120% after 10seconds.
Energy meter MID compliant
Load switching Contactor, 4-pole
Weld detection Contactor welding trips RCD
RFID ISO14443A/B, UID (4 Byte/7 Byte) only
Backend communication OCPP 1.6 via LAN or LTE/WIFI (optional)
Compliance standards IEC 61851-1
Control / customisation Internal RS485 interface, bus system
Ambient temperature -30°C to 40°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95%, no condensation
Class of protection I
Degree of protection (housing) IP54
Overvoltage category III
Impact strength IK08
Dimensions (H×W×D) 437×328×170mm
Weight per unit approx. 8kg approx. 10kg
* Structurally identical variant with one charging socket with shutter: 2W2242
Extender series
Model code 2W2230* 2W2231
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 22kW
Charging connection Type 2 charging socket, 1 pc Type 2 charging cable, 1 pc
Phase system 3-phase
Terminal blocks Direct connection to RCD, PE to rail mount terminal block, max. 5 × 16mm²
