Taking into operation and charging procedure
The mechanical and electrical installation of the ABL Wallbox model variant described
in this manual must always be carried out by qualified specialist personnel: Prepara-
tion of the domestic power supply, and electrical connection to your domestic power
supply in particular, must be carried out by a qualified electrical contractor, and subse-
quently inspected and approved as part of the process of taking the device into opera-
tion. Please contact a specialist electrical contractor or your local ABL partner, who will
be pleased to assist you with any questions regarding the installation and operation of
your wallbox.
Installation itself is described in the a separate installation manual. That manual con-
tains important information regarding mechanical and electrical installation as well as
regarding the subsequent functional inspection, approval and taking into operation of
the wallbox. It is advisable that you are present when the device is taken into opera-
tion for the first time by a qualified electric contractor to ensure that your are able to
easily carry out charging procedures with your ABL Wallbox.
The current operating status of the wallbox is indicated by the color LEDs in the lower
part of the housing cover. Each LED may ...
...
be illuminated
(continuous ON)
... flash
...
be extinguished
(continuous OFF).
You can find further information about operating states on the following pages.
Your wallbox is ready for use immediately after mechanical and electrical installation
have been completed. While the 3W2205 model variant has a fixed charging cable
with a Type 2 charging connector, the 3W2207 and 3W2209 model variants come with
one, the 3W2214, 3W2217 and 3W4401 with two IEC 62196-2 Type 2 charging sock-
ets each. To connect your vehicle to model variants with charging socket(s), you will
need the separately available charging cable. To provide a high level of flexibility, ABL
has two different cables on offer for this purpose:
MODEL NUMBER DESCRIPTION
MAXIMUM
OUTPUT
LAK32A3
Type 2 charging cable for connecting all eMH3
wallboxes and vehicles with charging socket in
acc. with IEC 62196-2 Type 2
22 kW
LAKK2K1
Adapter cable Type 2 to Type 1 for connection
to all eMH3 wallboxes with charging socket in
acc. with IEC 62196-2 Type 2, with charging
connector according to IEC 62196-2 Type 1
7.4 kW
