appendIx
27
Scale drawings and dimensions
The ABL Wallbox is delivered fully assembled and quality checked. All measurements
in the following elevations are in mm.
Wallbox 3W2205
Wallboxes 3W2207 and 3W2209
400
189
492
194
400
492
134
