IntroductIon
7
Unpacking and components included
Your ABL Wallbox is delivered in an extremely sturdy box, including a range of acces-
sory components required for proper operation. Therefore, please check immediately
after unpacking whether the following components are included:
COMPONENT QUANTITY DESCRIPTION
Wallbox 1
Wallbox, consisting of plastic housing with lockable
cover and separate mounting plate.
Quick start guide 1
Quick start guide including safety notices in printed
form
Installation kit 1
Set of fixings for wall mounting, consisting of 2 x 4
screws as well as matching wall plugs, triangular key,
strain relief including screws (2 pcs), sealing grom-
mets for openings at the back of the housing (3 pcs)
Should one or more components be missing after unpacking, please contact your local
ABL distributor immediately:
Identifying your model variant
The ABL Wallbox series comprises several model variants, which are mechanically and
electrically adapted to different usage profiles. A product sticker with the specific ABL
product identification number is located on the internal electronic components cover.
Please check the product sticker to ensure that the model variant you have installed is
the one described in this manual.
The model code (3WXXXX) as well as the
power supply ratings (voltage, frequency,
current) indicated below it are especially
relevant for proper identification.
The following wallboxes are described in this manual:
MODEL NUMBER GRID CONNECTION MODEL VARIANT
3W2205
230 / 400 V
50 Hz 32 A
Single charging station according to
IEC 62196-2 Type 2; integrated, factory
deactivated RFID module for access
control; internal Type A RCCB; internal
DC fault current detection; charging
output up to 22 kW
3W440100001
2016-08-17
3W4401
~230/400V 50Hz 2 x 32A
IP54
IEC 61851-1
IEC 61439-7 ACSEV
MADE IN GERMANY
ABL SURSUM Bayrische Elektrozubehör GmbH & Co. KG
3W440100001
