IntroductIon
9
MODEL NUMBER GRID CONNECTION MODEL VARIANT
3W4401
230 / 400 V 50 Hz
2 x 32 A
Twin charging station with two inte-
grated charging sockets according to
IEC 621
96-2 Type 2 with locking mech-
anism for separately available charging
cable (T
ype 2 to Type 2 or Type 2 to
Type 1); integrated, factory deacti-
vated RFID module for access control;
internal
Type A RCCB; internal DC fault
current detection; charging output of
up to 2 x 22 kW
WARNING!
The information and technical specifications contained in this manual relate
exclusively to the above-mentioned model variants and must not be trans-
ferred to other wallbox models. These variants are delivered with specific
instruction manuals where necessary.
Available accessories
ABL sells additional accessories for your eMH3 Wallbox. For the models of the eMH3
series, the following components are available:
DESIGNATION ARTICLE NO. QUANTITY
Type 2 charging cable
(model variants 3W2214, 3W2217 and
3W4401) for connection with all eMH3
wallboxes and vehicles with charging
sockets according to IEC 62196-2 Type
2, 32 A 240 / 415 V AC and IP44 splash
protection rating
Length: approx. 4 meters
LAK32A3
1
Adapter cable Type 2 to Type 1
(model variants 3W2214, 3W2217 and
3W4401) for connection to all eMH3
wallboxes with charging sockets accord-
ing to IEC 62196-2 Type 2, with charg-
ing connector according to IEC 62196-2
Type 1, 32 A 230 V AC, and IP44 splash
protection rating
Length: approx. 4 meters
LAKK2K1
1
