5. Monitor operation (2-wire & IP)
5.1 Live image
Button/display Description
Accepts the call and opens the video/voice
connection.
Ends a call and hangs up.
Saves an instant snapshot of the current video
Opens the doors. If multiple relay outputs are
used simultaneously, there will be up to 3 key
symbols. (2x door relays in door video module,
1x door relay in monitor).
For help connecting a door opener to the relay
or using the security module TVHS10040,
please see Installations and operating
information in section
“9.8 Connecting electrical door openers
to the video module (including “garden
gate”)” and
“9.1 Using the security module
(TVHS10040)”
