10. Exploded View and Parts List
10.1 Indoor Unit
The component picture is only for reference; please refer to the actual product.
No.
Description
Part Code
QTYAWH12QC-D3DNB8K/I AWH09QB-D3DNB8K/I
Product Code
CB438N08300 CB438N08100
1 Front Panel 20000300074T 20000300073T 1
2 Filter Sub-Assy 11122468 11122219 2
3 Display Board 30565260 30565260 1
4 Front Case Assy 00000200045 00000200040 1
5 Guide Louver 1051293101 1051276301 1
6 Helicoid Tongue 26112436 26112508 1
7 Left Axile Bush 10512037 10512037 1
8 Rear Case assy 00000100093 00000100066 1
9 Drainage Hose 05230014 0523001408 1
10 Ring of Bearing 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
12 Evaporator Supper 24212179 24212180 1
13 Cold Plasma Generator / / /
14 Evaporator Assy 0100297601 0100200004407 1
15 Wall Mounting Frame 01252484 01252043 1
16 Cross Flow Fan 10352056 10352059 1
17 Fan Motor 1501214604 1501208905 1
18 Connecting pipe clamp 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 1
20 Stepping Motor 1521210710 1521212901 1
21 Crank 73012005 73012005 1
22 Electric Box Assy 10000204740 10000203822 1
23 Axile Bush 10542036 10542036 1
24 Terminal Board 42011233 42011233 1
25 Jumper 4202021917 4202021911 1
26 Main Board 300002000315 300002000309 1
27 Screw Cover 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 0140206501 0140206501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 1
30 Electric Box Cover 2011220701 2011220701 1
31 Power Cord / / /
32 Connecting Cable / / /
33 Remote Controller 30510475 30510475 1
34 Detecting plate(WIFI) 30070077 30070079 1
