AC Pro A-Series - Installation Dimension Diagram; 8.1 Installation Dimension Diagram

INSTALLATION
INSTALLATION DIMENSION DIAGRAM
53
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
unit:inch
Space to the ceiling
Space to the wall
At least 8
At least 72
At least 6
At least 6
Space to the wall
Space to the obstruction
roolf eht ot ecapS
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstructi
o
Space to the obstruction
At least 24
At least 12
At least 24
At least 12
At least 78
At least 118
Space to the obstruction
