Analysing test results on the PC
Analysing test results on the PC
The meter has a built‑in USB (Universal Serial Bus) port for transferring saved test results to a computer
(PC) that is equipped accordingly. Roche Diagnostics oers a variety of special diabetes management
hardware and software products which enhance the integrated diary functions of your meter. With these
hardware and software products, you and your healthcare professional can manage your test results
more eectively and use graphs and tables to understand them better. For further information on diabetes
management products, please contact your customer support and service centre.
USB cable 1
The USB port
1
is located on
the left side of the meter.
To connect the meter to the
computer, you need a maximum
1.5 m long USB cable with a
Micro B connector and a USB‑A
connector. Plug the Micro B
connector
2
into the USB port
of your meter. Plug the USB‑A
connector
3
into a USB port of
your computer.
Plug the Micro B connector into
the USB port of your meter.
Plug the USB‑A connector into a
USB port of your computer.
1
2
3
USB port

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
