Accu-Chek ACTIVE User Manual

52
Symbols, problems and error messages
12
Symbols, problems and error messages
In addition to test results, time and date, other symbols and error messages also appear in your meter’s
display. The following provides an overview of all symbols and error messages. Please pay attention to all
symbols and error messages when you use the meter. If you do not recognise a symbol or do not
understand an error message, please refer to this chapter for an explanation.
Symbols
Symbols on the display
5
4
10
11
12
13
14
15
16
17
18
1 2 3
6
7
8
5
9
6
Symbol Meaning
1
You are in the test‑result memory. Either a saved test result or an average is
being displayed.
2
The battery is almost empty.
When the symbol first appears, you can perform approx. 50 more tests.
3
You are in the settings for the time format, time, date and beep.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
