Accu-Chek Aviva User Manual

23
8. The result appears on the
display, along with the control
bottle symbol and a flashing
“L.” Do not remove the test
strip yet. Press and release
once to mark the result as a
Level 1. If you tested the
Level 2 control, press and
release
a second time.
9. Press and release
to set the
control level in the meter.
10. The control result and “OK”
alternate on the display if the
result is in range. The range is
printed on the test strip
container label. The control
result and “Err” alternate on
the display if the result is out
of range. Remove and discard
the used test strip.

Accu-Chek Aviva Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Battery Life	Approximately 1000 tests
Memory	500 test results
Battery Type	1 x 3V lithium (CR2032)
Operating Humidity	10% to 90% RH
Meter Weight	59 g
Measuring Range	10 mg/dL to 600 mg/dL
Automatic Shut Off	After 90 seconds of inactivity
