Accu-Chek Compact Plus Reference Manual

105
Using the meter as an electronic notebook
5
You can exit memory at any time:
 To do this, press the Test button.
The meter turns off.
Notes
i
Always turn the meter on with the M button if you intend to
review results held in memory.
If you turn the meter on with the Test button and there is a drum
in the meter, a test strip will be advanced.
i
If no result has been saved in the meter, just three horizontal bars
are displayed.
AC_CP_LCM_Manual_EN-UK final.indd 105_CP_LCM_Manual_EN-UK final.indd 105 20.6.2007 11:04:2320.6.2007 11:04:23

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
