Inserting a Lancet Drum
You must first load the lancet drum into the lancing device to get it ready for use.
Remove the cap.
Insert a new lancet drum, white
end first, until it clicks firmly
into place.
1
Slide the cap on until it stops by
aligning the notch on the cap
with the notch on the lancing
device.
2
You are now ready to use the
first lancet.
The lancet counter shows a
number6, meaning you have
6new lancets remaining.
3
NOTE
Once the lancet drum is inserted into the lancing device, do not remove the lancet drum until
completely used. The lancet drum cannot be reused once it has been removed from the lancing device.
WARNING
You must not insert the lancet drum into the lancing device and simultaneously press the
release button or hold the lancing device with the release button resting on a surface such as a
table top. This could release a lancet and inadvertently cause injury.
