Accu-Chek Guide Me User Manual

7
Your New System
1
1. Power/Set Button
Turns the meter on or o and sets
options.
2. Display
Shows results, messages, and test
results stored in memory.
3. Left Arrow Button
Press to enter memory, adjust settings,
and scroll through test results.
4. Right Arrow Button
Press to enter memory, adjust settings,
and scroll through averages.
5. Test Strip Slot
Insert test strip here.
6. Battery Door
Open to replace batteries.
7. Micro USB Port
Transfers data from meter to a computer (PC).
The Accu-Chek Guide Me Meter
Chapter 1: Your New System
Front View Back View Side View
1
2
3
5
4
6
7
1080_Guide Me_MANUAL_MASTER.indb 7 3/5/2018 1:27:41 PM

Accu-Chek Guide Me Specifications

General

Display	LCD
Sample Size	0.6 µL
Test Time	Less than 4 seconds
Connectivity	Bluetooth
Measurement Range	10 to 600 mg/dL
Battery Type	2 x CR2032 3V lithium coin cells
Battery Life	Approximately 1000 tests
Weight	40 g (1.4 oz) with battery
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
