Accu-Chek Guide Me User Manual

16
The Accu-Chek FastClix Lancing Device
2
Remove the cap.
Hold the lancet drum between your thumb and index finger and pull
it straight out.
A red stripe is visible on the white part, indicating that the lancet
drum has been used.
Throw the old lancet drum
away.
Always discard according to
local regulations.
1
2
Insert a new lancet drum, white end first, until it clicks firmly into
place.
Slide the cap back on until it stops by aligning the notch on the cap
with the notch on the lancing device.
3
Changing the Lancet Drum
When you have used the sixth and last lancet, change the lancet drum.
1080_Guide Me_MANUAL_MASTER.indb 16 3/5/2018 1:27:48 PM

Accu-Chek Guide Me Specifications

General

Display	LCD
Sample Size	0.6 µL
Test Time	Less than 4 seconds
Connectivity	Bluetooth
Measurement Range	10 to 600 mg/dL
Battery Type	2 x CR2032 3V lithium coin cells
Battery Life	Approximately 1000 tests
Weight	40 g (1.4 oz) with battery
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
