1-18 Hardware Specifications and Configurations
Base View 0
Figure 1-6. Base View
Figure 1-7. Battery Release Latch/Lock
Table 1-6. Base View
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch/
lock
Releases the battery for removal.
Insert a suitable tool into the latch and slide to
release.
1
2
3
4 5
