Projector features and controls
Projector
# Item # Item
1. Zoom ring 13. Control port
2. Focus ring 14. Computer IN (D-SUB) connector
3. Lens 15. Monitor OUT
4. Ventilation holes (intake) 16. S-Video input
5. Ventilation holes (exhaust) 17. Y connector
6. Adjuster button 18. Cb connector
7. Front IR remote controller
sensor
19. Cr connector
8. Speakers 20. Audio input jacks (L & R)
9. Control Panel including
Power button
21. Composite Video input jack
10. AC power socket 22. Lamp cover
11. Rear IR remote controller
sensor
23. Air filter
12. Security lock receptacle
