AcerPower Minitower (M11E/IDCATX-2) User's Guide
cxxx
Your CD-ROM front panel may be
slightly different from the one shown
above.
1. Disc tray opens and closes for disc loading and removal
2. Headphone jack is used for attaching headphones or self-amplified speakers
3. Busy indicator lights up while data is being read from the disc; flashes during seek
operation
4. Headphone volume control adjusts headphone sound level
5. Emergency eject hole. Insert a rod to eject the tray manually
6. Audio play/Skip track control button plays and skips one information track of an
audio CD
7. Open/Close button opens or closes the disc tray
A.3.2 Rear View
Figure A-2 Rear Panel
