1.3.2 Jumper Settings
Table 1-1 Jumper Settings
Jumper Setting Function
Password Security
JP3 1-2
2-3*
Check password
Bypass password
BIOS
JP4 1-2*
2-3
Acer
Reserved
1.3.3 Connector Functions
Table 1-2 lists the different connectors on the system board and their respective functions.
Table 1-2 Connector Functions
Connector Function
CN1 SPS S/W Control
CN2 CPU thermal sensor connector
CN3 CPU fan connector
CN5 Power connector
CN6 Floppy disk connector
CN7 USB connectors
CN8 COM2 (lower left), COM1 (lower right), and
Parallel port (above)
