Table 1-2 Connector Functions (continued)
connector Function
CN9 Upper: PS/2 mouse connector
Lower: PS/2 keyboard connector
CN10 Enhanced IDE 2 connector
CN11 Enhanced IDE 1 connector
CN12 Hard disk LED connector
CN13 SCSI disk LED connector (for Combo Card)
CN15 Wake-on LAN connector
CN16 Power switch
CN19 Housing fan connector
CN20 Audio line-in connector
CN21 Modem Ring-in connector
CN22 Turbo LED connector
JP1 Power LED connector
JP2 System reset connector
JP5 Housing intrusion switch connector
