Acer Power - Disk Drives

AcerPower Minitower (M11E/IDCATX-2) User's Guide
xlvi
2.4 Disk Drives
Select Disk Drives to input configuration values for disk drives.
The following screen shows the Disk Drives menu screen:
Disk Drives
Diskette Drive A ...................... [1.44-MB, 3.5-inch]
Diskette Drive B ...................... [ None ]
LS-120 Drive as ....................... [ Normal ]
IDE Primary Channel Master
IDE Primary Channel Slave
IDE Secondary Channel Master
IDE Secondary Channel Slave
2.4.1 Floppy Drives
To enter the configuration value for the first floppy drive (drive A), highlight the Floppy
Drive A parameter. Press or key to view the options and select the appropriate
value.
Possible settings for the Floppy Drive parameters are:
• [ None ]
• [360 KB, 5.25-inch]
• [1.2 MB, 5.25-inch]
• [720 KB, 3.5-inch]
• [1.44 MB, 3.5-inch]
• [2.88 MB, 3.5-inch]
Follow the same procedure to configure floppy drive B. Choose None if you do not have a
second floppy drive.
