1.2.1 System Board Layout
1 PS/2 keyboard port
2 PS/2 mouse port
3 USB connectors
4 Serial port 2
5 Parallel port
6 Serial port 1
7 BIOS
8 ISA slots
9 PCI slots
10 AGP slot
11 Battery
12 Intel 82371EB
13 Primary IDE connector
14 Secondary IDE connector
15 FDD connector
16 Intel 440BX
17 DIMM sockets
18 Voltage regulators
19 CPU slot
20 Power connector
Figure 1-1 System Board Layout
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
15
