ACL CSC400 User Manual

33
2.1.14
Dual TC1&2 SD No
Option
Dual TC1&2 10C Difference Shutdown
Y/N
Yes / No
2.1.15
4-20 Out Settings
Menu
4-20mA Output Settings Menu
(Branch to submenu)
2.1.16
4-20 In 1 Settings
Menu
4-20mA Input 1 Settings Menu
(Branch to submenu)
2.1.17
4-20 In 2 Settings
Menu
4-20mA Input 2 Settings Menu
(Branch to submenu)
2.1.18
Purge Cycle 0s
Option
Purge Cycle Time
0s - 300s, Enables Pre-Purge is
greater than 0s
2.1.19
IGN Int-Purge 0s
Option
Extra Inter-Purge Time between Ignitor
relight trials.
0s - 240s
2.1.20
AUX1 Relay Settings
Menu
AUX1 Relay Settings Menu
(Branch to submenu)
2.1.21
AUX2 Relay Settings
Menu
AUX2 Relay Settings Menu
(Branch to submenu)
2.1.22
PWR Save Disabled
Option
Power Save Enable/Disable (Enable = turn
display off after 10 minutes of no button
activity)
Enabled/Disabled
2.1.23
PWR Fail Unlatch
Option
Power Fail Shutdown Latched/Unlatched
Latched/Unlatched (see pg 46)
2.1.24
High Temp Unlatch
Option
High Temp Shutdown Latched/Unlatched
Latched/Unlatched
2.1.25
Hi Tmp TC3 Latched
Option
TC3 High Temp SD Latched/Unlatched
2.1.26
High Gas Unlatch
Option
High Gas Shutdown Latched/Unlatched
Latched/Unlatched
2.1.27
Low Gas Unlatch
Option
Low Gas Shutdown Latched/Unlatched
Latched/Unlatched
2.1.28
Level Unlatch
Option
Level Shutdown Latched/Unlatched
Latched/Unlatched
2.1.29
Aux 1 Unlatch
Option
Auxiliary 1 Shutdown Latched / Unlatched
Latched/Unlatched
2.1.30
Aux 2 Unlatch
Option
Auxiliary 2 Shutdown Latched / Unlatched
Latched/Unlatched
Line Display Configuration Menu Options
The CSC400 allows the user to select what they wish to view on the top temperature / shutdown status screen. Lines 1 to 3
may be configured to show a variety of status and temperatures. Some selections show information on more than two lines.
Line 4 always shows shutdown status and Ignitor status (On, Off, Flame Fail "FF").
#
Line
Possible Selections
Type
Description
1
Line 1,
2, 3
TC1 temp w IGN1 setpoint
Option
Display TC1 Temperature and IGN1 Setpoint
TC1 temp w IGN2 setpoint
Option
Display TC1 Temperature and IGN2 Setpoint
TC2 temp w setpoint
Option
Display TC2 Temperature and Setpoint
TC3 temp w setpoint
Option
Display TC3 Temperature and Setpoint
TC1 TC2
Option
Display TC1 and TC2 Temperatures
TC1 TC3
Option
Display TC1 and TC2 Temperatures
TC2 TC3
Option
Display TC1 and TC2 Temperatures
TC1 TC2 TC3
Option
Display TC1, TC2, and TC3 Temperatures
4-20mA Input 1
Option
Display 4-20mA Input 1 measured value
(including desired units)
4-20mA Input 2
Option
Display 4-20mA Input 2 measured value
(including desired units)
FI mode: (2 lines) IGN1 Pilot, Main,
TMain status (On/Off)
Option
Display IGN1 Pilot, Main, and TMain solenoid
output status (On/Off) on 2 lines
FI mode: (2 lines) IGN2 Pilot, Main,
TMain status (On/Off)
Option
Display IGN2 Pilot, Main, and TMain solenoid
output status (On/Off) on 2 lines
FI mode: IGN1 P:ON/P:OFF,
M:ON/M:OFF, T:ON/T:OFF
Option
Condensed display of IGN1 Pilot, Main, and
TMain solenoid output status (On/Off) on one line
FI mode: IGN2 P:ON/P:OFF,
M:ON/M:OFF, T:ON/T:OFF
Option
Condensed display of IGN2 Pilot, Main, and
TMain solenoid output status (On/Off) on one line
Blank Line
Option
