ACL CSC400 User Manual

55
Inputs and Control Outputs:
Main Power Input, Voltage Range
10VDC (minimum) to 29VDC (maximum)
System Current Draw, no solenoid outputs on,
OLED display on, system off
350mA Max, 143 mA typical (at 12VDC)
System Current Draw, no solenoid outputs on,
OLED display off, system off
300mA Max, 100mA typical (at 12VDC)
System Current Draw, no solenoid outputs on,
Ignition module on, Max
620mA / 310mA (12VDC / 24VDC)
System Power Draw, no solenoid outputs on,
Ignition module on, Max
7.44W (no solenoids on)
4-20mA Inputs:
Allowable Voltage Input, 4-20mA mode
(Terminals 11 and 13)
12VDC minimum, 26VDC maximum (up to 24VDC
typical)
Allowable Voltage Input, 1V-5V mode
(Terminals 11 and 13)
0V-26VDC, 1V - 5V for input measurements, 0V
sensed as "open" or disconnected
Input Impedance
249 ohms, +/- 0.1%
Solenoid Outputs:
Voltage Output on Solenoid terminals
(12VDC main input)
Main Power Input minus a small voltage drop that is
dependent on current draw and temperature:
Solenoid outputs are 11.85V to 11.98V (approx.)
Voltage Output on Solenoid terminals
(24VDC main input)
Main Power Input minus a small voltage drop that is
dependent on current draw and temperature:
Solenoid outputs are 23.85V to 23.98V (approx.)
Voltage Output on Solenoid terminals
(10VDC main input)
Main Power Input minus a small voltage drop that is
dependent on current draw and temperature:
Solenoid outputs are 9.85V to 9.98V (approx.)
Maximum Allowed Continuous Output Current
per Solenoid Output
3A
Alarm / Status Contacts, AUX1 & AUX2
Solid-State Relays:
Maximum Voltage ("NC" to COM or "NO" to
COM)
30VDC, 30V
P
(AC)
Maximum Current ("NC" to COM or "NO" to
COM)
120mA
rms
/ mA
DC
Resistance ("NC" to COM or "NO" to COM)
35 ohms max
Physical Dimensions:
Length
10.750” (273.05mm)
Width
9.000” (228.6mm)
Height, maximum (from bottom of components
on bottom layer to top of components on top
layer)
1.130” (28.70mm)
