(emulating a "splitter" mode).
The 4-20mA output generates a current output relative to the measured
temperature on either TC1, TC2, or TC3 (selectable via the menu system).
This output can be configured as either a direct temperature conversion, a
proportional valve output, or it can output either 4-20mA Input reading
(emulating a "splitter" mode).
Proof of Closure input terminal connections
Remote Start/Stop input terminal connections
High Gas Shutdown input terminal connections
Shutdown
Low Gas Shutdown input terminal connections
Level Shutdown input terminal connections
Auxiliary Shutdown 1 input terminal connections
Shutdown 2
Auxiliary Shutdown 2 input terminal connections
Alarm Status output terminal connections
Terminals
Main 12-24VDC input terminal connections
Extra earth ground terminal connections to assist in providing stable ground
connections for solenoids, ignition modules, or other hardware
Mounting
The Ignition Module Mounting Location indicates the area where the ACL
Ignition Module may be installed.
Ignition Module
ACL Ignition Module 2 input terminal connections: "P"ower, "A"larm,
"V"alve, Ground.
"IGN2" can be enabled or disabled using the menu system.
Terminals for
Solenoids: IGN2
Terminals used for controlling power delivery to the solenoid valves for
Ignitor 2.
Main Fuse
Main 6.3A Input Fuse for Control Electronics & "IGN2" Pilot and Main
Solenoids.
Input 6.3A Fuse for TMain Solenoids for "IGN1" and "IGN2".
Input 6.3A Fuse for "IGN1" Pilot and Main Solenoids.
Ignition Module
ACL Ignition Module 1 input terminal connections: "P"ower, "A"larm,
"V"alve, Ground.
"IGN1" can be enabled or disabled using the menu system.
Terminals for
Solenoids: IGN1
Terminals used for controlling power delivery to the solenoid valves for
Ignitor 1.
