Acon Mission - Appendix 1 Meter Specifications

52
Appendix 1 Meter Specifications
Feature Specifications
Methodology Reflectance Photometer
Test Time ≤ 2 min
Measurement
Range
CHOL: 100-500 mg/dL (2.59-12.93 mmol/L,1 mmol/L=38.66 mg/dL)
HDL: 15-100 mg/dL (0.39-2.59 mmol/L, 1 mmol/L=38.66 mg/dL)
TRIG: 45-650 mg/dL (0.51-7.34 mmol/L, 1 mmol/L=88.6 mg/dL)
Specimen Whole blood, plasma, and serum
Specimen
Volume
10 μL for individual test; 35 μL for 3-in1 test
Power Source
4 AAA batteries (1.5V)
AC Adapter (Mini USB, 5V dc, 50 mA)
Battery Life 85 hours or 1,000 tests
Units of
Measurement
mg/dL, mmol/L
Memory 200 records
HCT 30 – 50%
Automatic
Shut Off
5 minutes after last use
Meter Size 137 mm × 79 mm × 26 mm (5.4” × 3.11” ×1.02”)
Display Size 50 mm × 50 mm (1.97” ×1.97”)
Weight 145g (without batteries)
Meter Storage
Conditions
0 - 50ºC (32 -122ºF); ≤ 90% RH
Operating
Conditions
15 - 40ºC (59 -104ºF); ≤ 90% RH
Meter
Connectors
USB cable for Data Transfer or Power (optional)
