System Log
The System Log menu allows the operator to view events in the historical event log, and to
request a printout of the entire log.
Display Log
The Display Log function allows the operator to view events in the historical log directly on
the LCD display. When this option is selected, the latest event in the log is displayed with the
time and date on the top line of the display, and the event details being scrolled across the
bottom line. Each log event will be displayed in turn (stepping backwards in time) until the end
of the log is reached. Pressing the 0 key advances immediately to the previous event without
waiting for it to be displayed. Pressing the key locks the current event on the display until
is pressed again. Pressing the key exits from the display log function.
Print Log
The Print Log function allows the user to request the immediate printing of the entire system
log on an attached serial printer. If real-time log printing is enabled, new events will be
buffered until the complete log print is completed. Note that selection of this function only
starts the log printing, and this may take a few minutes to complete. The display will indicate
that printing has commenced, and return to the previous menu. If this function is re-selected
before the log has been completely printed, then the option to stop the printout is given.
ACT recommends the Epson LQ-300:
Wiring between Printer & Controller: Controller Printer
0v TX RX SERIAL (25 way connector)
0V---------------------- PIN 7
TX---------------------- PIN 3
RX---------------------- PIN 20
Printer settings:
CHARACTER TABLE PC850
PAGE LENGTH OF TRACTOR 11 INCHES
SKIP OVER PERFORATION OFF AUTO TEAR OFF OFF
GRAPHIC PRINT DIRECTION BI-D SOFTWARE ESC/P2
AGM OFF AUTO LINE FEED OFF
INTERFACE SERIAL DATA LENGTH 8 BITS
BIT RATE 9600BPS EXT/ACK OFF
PARITY BIT NONE STATE REPLY OFF
Filter Log
The Filter Log function allows the user to prevent certain events from being entered on the
system log. Normally all events are logged, but to prevent ACTWin pro from having to store a
lot of information on a large installation, some events may be filtered out.
