200S 47
II - 1 Installation Setup
Select the encoder type by pressing the LINEAR/ROTARY soft key.
Arrow down to the RESOLUTION field.
Press COARSER, or FINER soft keys when using linear encoders to
select the encoder’s resolution in µm (10, 5, 2, 1, 0.5). The exact
resolution can also be typed in using the numeric key pad.
Rotary encoders require the number of counts per revolution to
be entered using the numeric key pad.
Arrow down to the REFERENCE MARK field.
Toggle the REF MARK soft key.
Select NONE for no reference signal, SINGLE for single reference
mark, POSITION TRAC (ENC 250) for an ENC 250 encoder, or
POSITION TRAC for an encoder with the Position-Trac™ feature.
Arrow down to the COUNT DIRECTION field.
In the COUNT DIRECTION field, select the count direction by
pressing the POSITIVE/NEGATIVE soft key.
When the encoder’s count direction matches the operators count
direction, select positive. When they do not match,
select negative.
Arrow down to the ERROR MONITOR field.
In the ERROR MONITOR field, select whether the system will
monitor, and display encoder errors by selecting ON, or OFF.
When an error message occurs, press the C key to remove it.
Press ENTER to save the settings entered, and move to the next
encoder setup, or press the C key to remove them.
To exit and save setting, press ENTER, then JOB SETUP.
The encoder resolution and count direction can also be
established by just moving each axis.
