Tips
There should be nearly an equal number of water drops (about 25 water drops) between bucket tips. If not,
adjust the calibration screws on the bottom of the 5-in-1 sensor until an equal number of water drops are
tipping the buckets. Then, restart the calibration procedure.
If you don’t hear the buckets tipping and see water dripping alternately out of each drain, there may be an issue
with the rain gauge or it’s an adjustment. See Troubleshooting on page 21.
Adjustment
If the rain gauge doesn’t register close to 1.06”, make an EQUAL adjustment to the two calibration screws on the
bottom of the 5-in-1 sensor. Turning screws clockwise increases rainfall; counterclockwise decreases rainfall.
To adjust the rainfall reading by 2% turn both screws 1/8 of a turn.
To adjust the rainfall reading by 4% turn both screws 1/4 of a turn.
To adjust the rainfall reading by 8% turn both screws 1/2 of a turn.
Watch the video at www.acurite.com/5n1
Specifications
TEMPERATURE RANGE
Outdoor: -40°F to 158°F; -40°C to 70°C
Indoor: 32°F to 122°F; 0°C to 50°C
HUMIDITY RANGE
Outdoor: 1% to 99%
Indoor: 16% to 98%
WIND SPEED 0 to 99 mph; 0 to 159 kph
WIND DIRECTION INDICATORS 16 points
RAINFALL 0 to 99.99 in; 0 to 2540 mm
WIRELESS RANGE 3301t / 100m depending on home construction materials
OPERATING FREQUENCY 433 MHz
POWER
Display: 4.5V AC adapter
6 x AA alkaline batteries (optional)
Sensor: 4 x AA alkaline or lithium batteries
DATA REPORTING
Wind Speed: 18 second updates; Direction: 30 seconds Outdoor temperatu
re & humidity: 36 second updates Indoor temperature & humidity: 60 secon
d updates AcuRite Conned CSV Data Logging: 12 minute intervals AcuRite
Conned to Online Portal/App: 18 seconds
DISPLAY MEMORY 512 kilobytes (not expandable)
AMITE amma SYSTEM REQUIR
EMENTS
Windows 8.1 / 8 / 7. 1 GHz or faster processor; 1 GB (32-bit) or 2 GB (644it
) of RAM; available L1511 port
High-speed internet is required for some advanced features of AcuRite Co
nnect, such as the AcuRite software and app.
