Data displayed on the image are:
• Semi inter-pupillary distance measuring, located on the top of the image. They represent the
measures between the center of the optic axis and the central vertical axis. Divided to the
left and to the right in correspondence to the side they will measure.
• On the bottom on the left and the right of the image you find the following distances (R stand
for Right Eye, while L for Left Eye):
- the greatest value and the distance between the center of the optic axis and the horizontal
axis (YR, YL).
- the lower value and the measure between the center of the optic axis and the
corresponding stud (XR, XL).
Under the image there are two other values that represent the head tilt and the distance
between the two centers of the optic axes.
The values written in brackets are the names of the report values.
Printing on SD and creating of the report
After locating the axis you can save their position (for a future review) by holding the Printing
button after exiting from the App. In this way it will create a report and the values will be
saved on the measuring and next time you will find them in the same position as you set
before.
