Page 32
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
The next number in the list of programmed receivers. The arrow buttons allow you to
scroll the list up and down, the buttons Insert Satellite and Remove Satellite allow
you to update the list of programmed receivers. In a multiple receiver installation
there can be maximum 4 receivers.
9.5.5.2. ID
Identifying number given to each receiver. The first receiver has to be given the
number 101. Valid values range from 101 to 104
9.5.5.3. Mode
Allows you to define the system’s connection mode.
Network
Choose RS-485 connection with Sysnet network.
9.5.5.3.1. Immediate transmission
Single RS-232 connection without the support of a transmission protocol.
Irrelevant.
9.5.5.3.2. Test site survey
Reserved for test procedures. Irrelevant.
9.5.5.3.3. Test echo
Reserved for test procedures. Irrelevant.
9.5.5.3.4. Test RSSI
Reserved for test procedures. Irrelevant.
9.5.5.4. Terminal from … to
Enter the first and last identifying number for the group of senders managed
by the receiver. If one sender must transfer data within the coverage range of
different receivers, its identifying number should be included in each group.
9.5.5.5. Group
Allows management of different receivers communicating with the same terminal to
be distinguished, so that no problems arise in the overlapping coverage zones.
By giving a different group number to receivers communicating with the same
sender, only one of these receivers to communicate is enabled, automatically
disabling transmission between that particular sender and receivers with a different
group number. In the same way, by giving the same group number to receivers
communicating with different senders, the connection can take place
simultaneously.
(see following example)
