AdderLink Innity browser-based conguration utility
The browser-based conguration utility within all TX and RX units requires a
network connection between the ALIF unit and a computer on the same network.
The conguration utility allows you to perform many important functions. Please see
Appendix A for TX unit details and Appendix B for RX unit details.
It is possible to gain access to the internal conguration utility via any of the ports
located on the front panel of each ALIF dual unit. For temporary connections on ALIF
dual units, you are recommended to use the Management port. There is no Management
port on ALIF 1002 models, so use the System port instead.
To connect a computer to access the conguration utility
1 Connect a CAT 5, 5e, 6, or 7 link cable to either the Management (ALIF dual only) or
System port socket on the front panel. The port automatically congures itself, so no
cross-over cable is required (but is supported if you do use one).
2 Connect the other end of the link cable directly to the network port of your
computer.
To access the browser-based conguration utility
1 Temporarily connect the ALIF unit and your computer, as discussed left.
2 Run a web browser on your computer and enter the IP address of the ALIF port that
you are using.
The default settings are as follows:
TX units RX units
Management port 192.168.1.42 192.168.1.42
System port 169.254.1.33 169.254.1.32
Teaming port 169.254.1.43 169.254.1.42
Note: Where the port addresses of a unit have been changed and are not known, providing it
is appropriate to do so, perform a manual factory reset to restore the default addresses.
The opening page of the ALIF conguration utility should be displayed:
You can nd further information about the conguration pages for the TX and RX
units within separate appendices later in this guide:
• Appendix A - Transmitter (TX) unit conguration pages
• Appendix B - Reciever (RX) unit conguration pages
Use the menu options to choose
the required conguration page
Û
ALIF dual only
Temporary link
from your computer
to the System port
Temporary
link from your
computer to the
Management port
ALIF dual ALIF 1002 (or dual)
