Management
port
Indicators
These six indicators clearly show the key aspects of operation:
• NET On when valid network link is present.
• SER On when the AUX (serial) port is enabled and active.
• AUD On when audio is enabled and active.
• USB On when USB is enabled and active.
• DVI On when DVI video is enabled and active.
• PWR Power indicator.
Indicators
These six indicators clearly show the key aspects of operation:
• NET On when valid network link is present.
• SER On when the AUX (serial) port is enabled and active.
• AUD On when audio is enabled and active.
• USB On when the USB link with the connected PC is active.
• DVI On when a video input signal from the PC is detected.
• PWR Power indicator.
ADDERLINK INFINITY DUAL UNIT FEATURES
The ALIF dual units are housed within durable, metallic enclosures with most connectors situated at the rear panel -
the Ethernet ports are situated on the front panels. The smart front faces also feature the operation indicators.
ALIF dual (2002 and 2020) transmitter - front ALIF dual (2000 and 2020) receiver - front
System
(Gigabit
Ethernet)
port
DVI-D-2
5V 4A
DVI-D-1
AUX
COMPUTER
ON
21
INDOOR
USE ONLY
OPTIONS
1 2
DVI-D-1
5V 2.5A
DVI-D-2
IN OUT
ALIF dual (2000 and 2020) receiver - rearALIF dual (2002 and 2020) transmitter - rear
Primary
video
input
Audio
line
in/out
AUX
(serial)
port
USB
port
Options
switches
(further details)
Power
input
Secondary
video
input
Audio
line
in/out
USB
ports
Power
input
Secondary
video
output
Primary
video
output
AUX
(serial)
port
Teaming
port
Teaming
port
Management
port
System
(Gigabit
Ethernet)
port
Options
switches
(further details)
2020 version
only
2020 version
only
