26
◆ When do a calibration task for a HART transmitter, select the HART process value to be calibrated.
4. Settings
(1) Parameters
◆ In main operation page, switching into HART, then press to enter the HART parameters setting
interface, seeing Table 12.
Table 12 HART Parameters
Item
Parameters
Description and effective value
Device
information
Label
Support letters, numbers, symbols input, the length cannot be greater than 8
characters
Date
Any date supported by the transmitter can be changed
Infor.
Support the input of letters, numbers, and symbols, and the length cannot be
greater than 32 characters
Description
Support letters, numbers, symbols input, the length cannot be greater than 16
characters
Final assembly No.
Support integer input, the length cannot be greater than 8 digits
Leading character
number
Support integer input, the range is 5~20
Manufacturer
Read only parameter
Device type
Read only parameter
