46
Input
Depends on transmitter
Transmitter pressure scale
Output
Analog signal: 4~20Ma, 0~10mA, 0~20mA,
1~5V, 0~5V, 0~10V, custom
Signal output range of circuit/voltage pressure transmitter
HART device: PV, percentage, output circuit,
loop circuit
Signal output type of HART device
Transfer
function
Depends on input/output relationship
Pressure transmitter transfer function
Accuracy
0.05%, 0.1%, 0.2%, 0.5%,
1%, 1.5%, 2%, 2.5%, custom
The accuracy of the pressure transmitter. The value entered in
the custom option is the accuracy level of the pressure
transmitter
3. Start the task
(1) Operations refer to the content in Para. 4.1.
(2) If output analog signal, it needs to set the power configuration;
(3) If output to HART device, it needs to configure HART.
(4) Click on and to zero the module;
4. Finish task
Operations refer to the content in Para.4.1.
