Effect diagram after assembling
4. Fix one 3-CH WS2812 RGB LED-A on M2*6 Copper Standoff.
Assemble the following components
M2 Nut x2
3-CH WS2812 RGB LED-A
input (the end marked
with a white strip pattern)
is on the back.
3-CH WS2812
RGB LED-A
x1
