Effect diagram after assembling
5. Follow step 3 and 4, fix another 3-CH WS2812 RGB LED-A on A01.
Before install the 3-CH WS2812 RGB LED-A,
pass the 3-Pin Wires-A on the 3-CH WS2812
RGB LED-A through A01 via the hole here.
3-CH WS2812 RGB
LED-A input (the end
marked with a white
strip pattern) is in the
front.
